3015 carbon steel/aluminum cnc fiber laser cutting

Basic Info

Model No.UT-3015

BrandUTECH

FunctionMetal Cutting

Laser Power500W /750W/ 1000W / 2000W / 3000W

Motor And DriverJapan YASKAWA Servo Motor And Driver

Axial Positioning Speed+-0.03mm/m

Power RequirementAC380V/50Hz

Max Table Load1200kg

Product NameCarbon Steel Fiber Laser Cutting Machine

Laser Cutting HeadGerman Preste/Empower Cutting Head

Guide RailGermany Rexroth Rail Guide

ReducerKOFON Reducer 1:7

Additional Info

PackagingPlywood case for Metal laser cutting machine.

Productivity50sets/month

TransportationOcean,Land

Place of OriginJinan, Shandong Province

Supply Ability50sets/month

CertificateISO9001

HS Code8456110090

PortQingdao,Shanghai,Ningbo

Payment TypeL/C,T/T,D/P,Money Gram

IncotermFOB,CIF

Product Description

3015 carbon steel/aluminum cnc fiber laser cutting


»Advantages of 500w Fiber Laser Cutting Machine

•Excellent beam quality:  Smaller focus diameter and high work efficiency, high quality.
•High cutting speed: Cutting speed is more than 20m/min
•Stable running: Adopting the top world import fiber lasers, stable performance, key parts can reach 100,000 hours;
•High efficiency for photoelectric conversion:  Compare with CO2 500w fiber Laser Cutting Machine, fiber 500w fiber laser cutting machine has three times photoelectric conversion efficiency
•Low cost & Low maintenance: Save energy and protect environment. Photoelectric conversion rate is up to 25-30%. Low electric power consumption, it is only about 20%-30% of traditional CO2 500w fiber laser cutting machine. Fiber line transmission no need reflect lens, save maintenance cost;
•Easy operations: fiber line transmission, no adjustment of optical path;
•Super flexible optical effects:  Compact design, easy to flexible manufacturing requirements.



metal laser cutting machine

cnc laser metal cutting machine


Technical parameters


Model    UT-3015
Working area    3000*1500mm
Max moving speed    100m/min
Max working speed    1G
PositionaI accuracy    0.07mm
Repositioning resolution    0.02mm
Optional working area    4015/4020/6015/6020/6025
Laser power    2000W/1500W/1000W
Cutting thickness    16mm/12mm/10mm

fiber laser cutter for carbon steel


Fiber laser cutting machine's features


1. The world's top fiber lasers and laser power supplies are used. Modular and redundant design; small size, light weight, easy to move; easy to integrate, stable performance, and the overall quality of the product is safe.
2. An automatic laser head is used. The focus can be adjusted automatically, suitable for a variety of focal lengths; auto focus function, capacitive sensing, fully automatic follow-up system; composite lens, built-in water-cooled structure; double water-cooled constant temperature for collimation and focusing components; drawer type lens holder, Replace the protective lens quickly; smooth and efficient airflow design; adapt to various fiber lasers; short, long focal length common, can achieve the best cutting effect of thin or thick plate; all equipped with collimating protective mirror, better protection collimating mirror; The QBH circumferential position is adjustable, ensuring that each QBH red dot faces outward, facilitating the insertion and removal of the fiber head; the focus position visible window ensures that the input focus is exactly the same as the output focus.
3. Machine base. The whole cast iron bed is used for better stability and shock resistance and higher cutting quality.
4. Transmission system. It adopts high-precision rack and double-drive transmission and adopts imported servo system to ensure the accuracy of the machine under high-speed motion.
5. It adopts professional PC industrial computer operation, graphical interface, convenient operation, professional cutting control software can freely design all kinds of graphics and text, instant processing, support CAD, CorelDraw and other professional drawing software.
6. WIFI wireless remote control. Equipped with wifi wireless control, remote diagnosis can be realized, which greatly reduces the waste of time and money caused by personnel: by looking at the laser parameters, analyzing the cause of the laser failure; checking the cutting process parameters by the control system software, troubleshooting the cutting fault.
7. High power double cooling water cooler (can refrigerate laser and laser head at the same time). With perfect cooling system, the whole machine operates stably, efficiently and durable.
8. Other main accessories. The imported electric proportional valve provides a strong foundation for the machine to operate for a long time with high precision.
9. High standard production system. Full assembly process inspection, all detection records are kept for customers to check at any time.
10. The whole series is equipped with electronic control cabinet temperature, humidity controller, stable equipment under constant time electronic control system stable operation.


Fiber laser cutting machine's main machine parts




sheet metal laser cutting machine

stainless steel laser cutting machine
