Multi-functional cutting machine with CCD

Basic Info

Model No.Sofia-oscillating-CCD

BrandUtech

Machine Weight1200KG

Resolution0.01mm

Spindle Speed0-24000rpm

Command CodeHPGL G-code

Travel Speed0-25000mm/min

Working Speed0-18000mm/min

Table StructureVacuum Table

Driving ModeHybrid Servo Reducer Structure

Working Area1300mm*2500mm*200mm

Spindle Power7.5KW Air/water Cooled Spindle Motor

Additional Info

PackagingWooden case packing

Productivity1000 sets

TransportationOcean,Land,Air

Place of OriginChina

Supply Ability1000 sets per month

CertificateISO 9001

HS Code8465990000

PortQingdao,Shanghai,Shenzhen

Payment TypeL/C,T/T,D/P,Paypal,Money Gram,Western Union

IncotermFOB,CFR,CIF,FCA,CPT

Product Description

Multi-functional cutting machine with CCD

Multifunction cutting machine is applied in carpet, packaging, advertising, cloth, bag, footwear, gasket, construction industries. According to different requirements of clients, Multifunction cutting machine can be equipped with multi-functional combined cutting tools, CCD positioning system, projector and other good quality components or devices. It is easy for users to learn and operate.

cnc router with oscillating knife

Transmission Device: X, Y axis:  Precision helical tooth gear transmission; Z axis: Precision tBI ball screw
Driving mode: Hybrid servo reducer structure
Spindle power: 7.5KW air/water cooled spindle motor
Diameter of cutter: φ3.175-φ12.7mm
Command code: HPGL G-code
Working voltage: AC220V/Hz
Device interface: Standard PCI/USB interface optional
Resolution: 0.01mm
Machine size(W*D*H): 2135*3400*2120mm
Warranty: 12 months
Weight: 1200kg
