1325 wood furniture carving cnc machine with Mach3

Basic Info

Model No.UT-1325 CCD

BrandUTECH

Working Area1300*2500mm

Spindle Speed0-24000rpm

ApplicationFurniture, Advertising, Sheet Metal, Etc

TransmissionXY Axis By Helical Gear Transmission, Z Axis By TBI Ball Screw

SoftwareArtcam/Type3, Etc

Table StructureT-slot Aluminum Table/Vacuum Table

Driving ModeStepper Motor&driver

Product NameCnc Router With CCD Vision System

Control SystemTROCEN Visual Orientation Cutting Contro

Spindle Power3.5kw Air Cooled Spindle

Additional Info

PackagingAll Cnc Router are packed with standard inner plastic wrap and outer plywood case, inner package would be help to tight all the small parts in the package.

Productivity50 sets/month

TransportationOcean,Land

Place of OriginJinan, Shandong Province, China

Supply Ability50 sets/month

CertificateISO9001

HS Code8456990000

PortQingdao,Shanghai,Guangzhou

Payment TypeL/C,T/T,D/P,Money Gram,Western Union

IncotermFOB,CIF

Product Description


1325 wood furniture carving cnc machine with Mach3

Our Service ( professional person 24 hours online )

1. The Whole machine guarantee for 12 months.
2. 24 hours online service, free technical support lifetime. We hope every customer can use our machine easily and have a fun of it. If you have any problems of machine in 2 or 3, 5 years , please feel free to contact us. We will always be here .
3. Machine will comes with manual instruction and operation disk (Guiding Videos) for software Installation, operation and machine's using and maintenance.
4. We will provide the consumable parts at an agency price.
5. Machine has been adjusted before delivery, pls kindly tell us If there is any other questions.


Application:

Woodworking industry : furniture, musical instruments, wooden crafts, solid wood door, MDF paint-free doors and windows, composit panel, which all can be ideally processed
by our 1325 cnc wood carving machine.
Decoration industry : art model, wall art, screen relief engraving and cutting, decorating processing, gifts wrapping, waved plate, sports equipment, etc.
Advertising industry : acrylic, double color plates, PVC, ABS board, aluminum plate, artificial stone, organic glass, character, sign, trademark, etc.

cnc router 1200x1200

Main Features


1) The heavy duty thickened bed is welded by square pipe, side hanging structure, heavy column, 150*200mm gantry and X shaft dustproof.
2) German ASK 20 linear guide+ Flange slider
3) JMC 860 driver+450B stepper motor+1:4 patent gear reducer
4) Z axis plate with precision machined aviation aluminum T6061/6063, CNC processing center precision manufacturing.
5) Japan Omron limit photoelectric switch
6) Taiwan TBI ballscrew
7) Patent pressing clamp, convenient to fix the material
8) 3.5kw air cooled spindle
9) Mach 3 or DSP controller
10) Independent control cabinet
11) CCD function


Technical parameters


1325 woodworking cnc router machine

Please kindly note the above configuration is standard configuration.
Custom Made/ODM/OEM is available. Just tell us your requirement, we will build the machine accordingly.


Detailed Images


1) CCD camera
The machine comes with a camera to realize the vision function.
2) Machine head
The vision system Cnc Router Machine comes standard with 3.5kw high frequency air cooled spindle. This precision spindle requires no maintenance. Fully programmable speeds from 6000 to 24000 RPM, more powerful and less noise.
3) Vision system
- CCD and dual color adjustable LED light
- Software: TroCCDCut
- System Requirement: WinXP,Vista,Win7,Win8,Win10
- Accurate positioning cutting
- Subtle stretching and auto compensation
- Auto recognition cutting
- Real-time contour recognition
- Compatible with various graphic design software
4) Stepper motor&driver+Patent type reducer
Patent design 1:4 gear reducer install on the driving motor, makes the motor is more powerful, and having a longer time service life.
5) X axis dustproof structure
X axis dustproof structure for protecting ball screw and gear rack from dusting.
6) Patent pressing clamp
The patent design pressing clamp is convenient for the user to assemble and disassemble the material.
7) Spindle Fixing plate
The spindle is fixed on the high quality aviation aluminum T061/6063 plate, the plate is machined by high precision CNC machining center.
8) Transmission
Precision 1.25module helical rack+Taiwan TBI ball screw
1. Higher efficiency than traditional ball screws
2. Gothic groove shape, the shaft direction clearance can be adjusted to a minimum and can be easily transferred
3. The internal circulation method is applicable to many different scenes, and the circulation method is selected according to its own needs.
4. Use rigorous materials, high heat treatment and processing technology to supply durable products.
9) Helical rack+Germany ASK/PMT/GC-HIWIN 20 linear guide
10) Tool sensor
Automatic tool calibration pad allows for easy and accurate [Z" zero position for single and multiple tool changes through the program.

cnc router machine

woodworking cnc router

cnc router machine price


Customer feedback


CNC Engraving Machine for Acrylic Advertising Wood


Samples


aluminum sheet cnc engraving machine


Packing & Delivery


UTECH have professional design team and technical person, any machine size and appearance all can customized for you. UTECH have Cnc Router Series , include Mini Desktop Cnc Router, Advertising Cnc Router, Woodworking Cnc Router, Professional Stone Cnc Router, Sign Cnc Router , ATC Cnc Router ; Vision Localization/CCD Series include Cnc Router With CCD, Oscillating Knife Cutter With Ccd.

wood door making machine cnc router machine


Atc Cnc Woodworking Cnc Machine
