CNC router woodworking machine with CCD camera

Basic Info

Model No.: UT-1325 CCD

Working Area: 1300*2500mm

Spindle Speed: 0-24000rpm

Application: Furniture, Advertising, Sheet Metal, Etc

Transmission: XY Axis By Helical Gear Transmission, Z Axis By TBI Ball Screw

Software: Artcam/Type3, Etc

Table Structure: T-slot Aluminum Table/Vacuum Table

Driving Mode: Stepper Motor&driver

Product Name: Cnc Router With CCD Vision System

Control System: TROCEN Visual Orientation Cutting Contro

Spindle Power: 3.5kw Air Cooled Spindle

Additional Info

Packaging: All Cnc Router are packed with standard inner plastic wrap and outer plywood case, inner package would be help to tight all the small parts in the package.

Productivity: 50 sets/month

Brand: UTECH

Transportation: Ocean,Land

Place of Origin: Jinan, Shandong Province, China

Supply Ability: 50 sets/month

Certificate: ISO9001

HS Code: 8456990000

Port: Qingdao,Shanghai,Guangzhou

Product Description

Cnc Router woodworking machine with CCD camera

Main Features

1. Adopt the advanced CCD control system, image edge cutting with the camrea, engraving and processing integrated board without switching cables.
2. Configured with high accuracy linear rail and helical rack, more stable.
3. Be compatible with many CAD/CAM software like TYPE3/ARTCAM/CAS, ATE/PROE/UG/ARTGRAVE etc.
4. Standard with computer control unit, strong and week electrial seperation, more convenient maintenance.
5. Standard with 3kw high speed water cooling spindle
6. Configured with big torque transmitting motor with high subdivision drive, cutting efficiency is higher and more precise.

cnc router 1200x1200

Applicable industries and materials

* Advertising industry:
Acrylic cutting, density board cutting, snowflake cutting, double color board carving, various advertising boards.
* Furniture industry:
Cabinet doors, wooden doors, solid wood, mahogany furniture, antique furniture, all kinds of composite sheet cutting carving.
* Plate processing industry:
Insulation board, plastic work piece, PCB board, anti-double board, epoxy resin, ABS, PP, PE and other carbon mixtures.
* Crafts industry:
Artificial marble, PVC, wood, plexiglass, copper aluminum and so on.
* Decoration industry:
The screen, wave plate, wood, artificial marble, organic board, decorative board, double color board and other materials on various exquisite patterns and text carving.

Technical parameters

1325 woodworking cnc router machine

Please kindly note the above configuration is standard configuration.
Custom Made/ODM/OEM is available. Just tell us your requirement, we will build the machine accordingly.

Detailed Images

1) CCD camera
The machine comes with a camera to realize the vision function.
2) Machine head
The vision system Cnc Router Machine comes standard with 3.5kw high frequency air cooled spindle. This precision spindle requires no maintenance. Fully programmable speeds from 6000 to 24000 RPM, more powerful and less noise.
3) Vision system
- CCD and dual color adjustable LED light
- Software: TroCCDCut
- System Requirement: WinXP,Vista,Win7,Win8,Win10
- Accurate positioning cutting
- Subtle stretching and auto compensation
- Auto recognition cutting
- Real-time contour recognition
- Compatible with various graphic design software
4) Stepper motor&driver+Patent type reducer
Patent design 1:4 gear reducer install on the driving motor, makes the motor is more powerful, and having a longer time service life.
5) X axis dustproof structure
X axis dustproof structure for protecting ball screw and gear rack from dusting.
6) Patent pressing clamp
The patent design pressing clamp is convenient for the user to assemble and disassemble the material.
7) Spindle Fixing plate
The spindle is fixed on the high quality aviation aluminum T061/6063 plate, the plate is machined by high precision CNC machining center.
8) Transmission
Precision 1.25module helical rack+Taiwan TBI ball screw
1. Higher efficiency than traditional ball screws
2. Gothic groove shape, the shaft direction clearance can be adjusted to a minimum and can be easily transferred
3. The internal circulation method is applicable to many different scenes, and the circulation method is selected according to its own needs.
4. Use rigorous materials, high heat treatment and processing technology to supply durable products.
9) Helical rack+Germany ASK/PMT/GC-HIWIN 20 linear guide
10) Tool sensor
Automatic tool calibration pad allows for easy and accurate [Z" zero position for single and multiple tool changes through the program.

cnc router machine

woodworking cnc router

cnc router machine price
